Synchronization Control P3 LED Video Wall High Definition LED Billboard Display

Brand Name : SC

Model Number : SMDP3

Certification : CCC IP68 CE ISO9001 ROSH

Place of Origin : SHENZHEN CHINA

MOQ : Square Meters / 1 Piece

Price : Negotiable

Payment Terms : L/C, D/A, D/P, T/T

Supply Ability : 5000 Square Meter/Square Meters per Month

Delivery Time : 10 days after received deposit

Packaging Details : Wooden box, Flight Case

Best Viewing Angle : 3m~10m

Module Size : 192*192mm

Color : 1R1G1B

Cabinet Size : 576mm*576mm

Pixel Density : 111111dots/sqm

Cabinet Dimension : 576*576mm

Port Type : HUB75-A

Contact Now

High Brightness SMD P3 Led Video Panels , High Definition LED Billboard Display





Why Choose us?
We has a perfect service system, including pre-sale service, in-sale service and after-sale service. To provide high quality service for our customers, we train every salesman with necessary product maintenance knowledge and organized a Technology Supporting Department with a group of excellent and professional engineers. Any problem you can contact us at any time you like.
Pre-sale service:
1. Reply enquiries in 24 hours.
2. Market research and forecast for customer.
3. Provide unique and professional solutions based on customer's requirement.
4. Data sheet and samples offer.
5. Other services, such as special packing design, factory visiting and so on.
In-sale service:
1. Tracking report in producing.
2. Quality test report for every order.
3. Photos and videos as per customer's requirement.
4. Free spare parts.
After-sale service:
1. Lifetime free maintenance and upgrade.
2. Complaint respond period not exceed 24 hours; maintenance guidance and problem solution supplied in 48 hours.
3. Customer satisfaction tracking report.
4. Free technician training.
5. Full set of documents free of charge, which including installation guidance, software operation manual, easy maintenance manual and control system software CD and so on.
6. Special service for big project, such as stadium, exhibitions, squares and so on.

PARAMETERS:


Power

  Working voltage AC110～220V±10%
 Average Power consumption 150W/㎡
 Max.Power consumption <650W/㎡
 Current <20mA(single LED)


Control system

  CPU Pentium4 or above P4
 Operation system WIN98/2000/NT/XP/WIN7
 Control method Synchronization


Main technical
parameter

  Driving device Constant drive IC
 Refresh frequency >1080HZ
 Grey scale/colors


4096gray level/16.7M colors
 MTBF >9000hours
 Power switch Automatic switch
 Display Mode ≥800*600/1024*768

Cabinet

  Dimension 576mm*576mm
 Monomer Module Number 9pcs
 Power supply 5V/60A*1pcs
 Thermal discharge fan 2pcs
 Pixel per cabinet 192*192
 Best viewing distance 3M～10M
 Best viewing angle 110°(W)110°(H)
 Temperature

storage:-35℃～+85℃
working:-20℃～+50℃
 Relative humidity 10%-95%
 Thickness 55mm






Synchronization Control P3 LED Video Wall High Definition LED Billboard Display
Packing:


Project Cases:
Synchronization Control P3 LED Video Wall High Definition LED Billboard Display
