Commerical P8 Curved Led Panels , 6500Nits Brightness Led Outdoor Advertising Screens
Product Features:
1, Pixel density is 15625 pixels per square meter, high resolution guarantee superior performance even with small screen size, thus could meet every kind of requirements from clients.
2, Protection level is IP65, is full waterproof, dustproof, anti-corrosion and anti-ultraviolet, enable themselves to work in all weather conditions to guarantee durability, reliability and steady.
3, High brightness ensures the spectators far from the screen can still enjoy what is shown, even under direct sunlight.
4, High refresh rate, high grey scale level and high accurate color consistency guarantee the vivid pictures and perfect videos.
5, Super wide viewing angle and have best view in different position (can be visible in most corners), could give you visual enjoyment in most corners.
6, SMD3535 technology could guarantee higher flatness and better performance.
7, Aviation plug and quick lock is used, bringing easier cables connection and quicker assembly of cabinets to save time.
Parameter
| Unit Module | Item | Parameter |
| | Model Number | SF-SS8-4-A |
| | Module size | 256mm*128mm |
| | Pixel pitch | 8mm |
| | Pixels Density | 15625 Pixels /m2 |
| | Pixel configuration | 1R1G1B |
| | LED Package mode | Nationstar SMD3535 |
| | Pixel resolution | 32dots(W)*16dots(H) |
| | Max Power | 25W |
| | Module thickness | 22mm |
| | Module Weight | 0.37kg |
| | Drive type | Constant drive |
| | Scan mode | 1/4 |
| | Port type | HUB75-A |
| | Brightness of white balance | ≥6000～6500cd/m2 |
| | |
| LED Cabinet | Dimension | 1024mm*768mm*100 mm |
| | Monomer Module Number | 24pcs |
| | Power supply | 5V/40A*4 pcs |
| | Thermal discharge | fan 2pcs |
| | Pixel per cabinet | 128mm*96mm |
| | Best viewing distance | 8M～15M |
| | Best viewing angle | 120°(W) 110°(H) |
| | Temperature | storage:-35℃～+85℃ working:-20℃～+50℃ |
| | Relative humidity | 10%-95% |
| | Thickness | 122mm |
| Power | Working voltage | AC220V±10% |
| | Average Power consumption | 330W/㎡ |
| | Max.Power consumption | ≤1100W/㎡ |
| | Current | ≤20mA(single LED) |
| Control system | CPU | Pentium4 or above P4 |
| | Operation system | WIN98/2000/NT/XP/WIN7 |
| | Control method | Synchronization |
| Main technical parameter | Driving device | Constant drive IC |
| | Refresh frequency | ≥1200HZ |
| | Grey scale/colors | 4096,16.7MColor 4096gray level/16.7M colors |
| | MTBF | ≥9000hours |
| | Power switch | Automatic switch |
| | Display Mode | ≥800*600/1024*768 |
Application:
Widely used in Advertising media, Concert, TV SHOW, Super mall, Entertainment, School, Government, Trading conversation, Commodity fair, Exhibition, Cinema, News conferences, Meeting room, Airport, Hotel, Station Hall and other Public Places.
